Michalak NSM Container loader NSM 120.160

Bács-Kiskun county, 6060 Tiszakécske

Sharing:

2

Description
The NSM 120.160 is designed for the automatic loading of box pallets of 1200-1600×1200 mm in size and 1200 mm maximum height. The filling process starts by lowering the conveyor belt to the bottom of the box.

An integrated sensor system allows automatic control of the position of the belt, ensuring uniform product distribution and constant drop height throughout the filling cycle.

The filling unit is equipped with a set of operating parameters such as:
*filling speed,
* belt speed,
*speed and range of vertical movement (belt raising/lowering).

An automatic product layer thickness sensor monitors the current filling level of the pallet boxes and allows accurate material dosing. The machine is controlled via a touch panel, which allows the configuration of operating parameters and monitoring of current operating data. The machine has a capacity of 20 box pallets per hour.

Optional available SH32 65x400 conveyor belt.

Michalak's range also includes the NSM 160.240 filler for automatic filling of crates from 1600 to 2400 mm x 1200 mm with a maximum height of 1200 mm.

Standard equipment:
* Steady control of the filling speed
*Smooth adjustment of the shift, lowering and lifting of the belt
*Automatic product layer thickness sensor
*Rigid construction
*Intuitive machine control with touch panel

Optional equipment:
*Weight feeding for two stations
*SH32 65x400 conveyor belt feeding NSM filler

H/W/Weight: 278/120/230 cm
Capacity: 20 box pallets/hour.
Weight: 600 kg
Installed power: 2 kW/10A
Power supply: 3x400V+N+PE, socket: 5x32A
