Jansen HS-20DS63 hydraulic log splitter, 20 t, horizontal, bidirectional operation

724.000 HUF +VAT

Bács-Kiskun county, 6000 Kecskemét

Sharing:

6

Description
Engine: 4-stroke Kohler OHV engine, 6.5 hp, 4.8 kW

Fuel type: petrol

Fuel tank capacity: 3.6 litres

Fuel consumption: approx. 1.0-1.2 L/hour

Starting: manual starter with hand lever

Weight: approx. 180 kg without liquids

Wood loading platform height: 65 cm

Towing speed: max. 25 km/h

Maximum log opening: 60 cm

Cylinder speed in one phase: approx. 7 seconds

Breaking force: 20/17 tonnes (measured value)

Length of splitting wheel: 20 cm (included)

Packaging dimensions: 133×80×59 cm (HxWxD)

Engine oil volume: approx. 1 L (10W40 or 15W40)

Hydraulic oil volume: approx. 10 L (HLP46)

Hydraulic system capacity: 38,6 L/min

Hydraulic pressure: 240 bar

Wheel size: 10 inches

Dimensions: 228×102×100 cm (HxWxD)

Dimensions with packaging: 133×80×58 cm (HxWxD)

Weight including packaging: 221 kg

We have five locations in the country where you can pick up your order in person.

You can pick up at a prearranged time or have your order delivered to your door at a special price!
