URBAN EM110 shredder with conveyor belt 2,6 m

Spišské Podhradie, 053 04 SLOVAKIA

Sharing:

13

Description
The URBAN EM110 shredder is powered by an 18.5 kW Siemens three-phase electric motor. Power from the motor is transmitted by a V-belt to an oil-filled gearbox which drives the shredder. The EM110 is ideal for processing scrap materials (boards up to 280 mm wide, laths, trimmings) and smaller trunks and branches up to 12 cm in diameter. The resulting chip length is 7-22 cm.

Up to 120 mm diameter
The machine is supplied with: instructions for use, including declaration of conformity

Weight: 1048 kg
Max. fresh softwood (pine) diameter: 120 mm
Max. diameter of fresh hardwood (oak, hornbeam): 100 mm
Max. diameter of dry hardwood (oak, hornbeam): 80 mm
Max. prism dimensions (spruce): 100 x 100 mm
Max. board dimensions (spruce): 280 x 40 mm
Lath length (non-adjustable): 7 - 22 cm
Opening for control unit: 290 x 290 mm
Tank inlet opening: 800 x 600 mm
Chopping speed: 160/min
Maximum output:
