URBAN HM70 with conveyor 2, 1M shredder

Spišské Podhradie, 053 04 SLOVAKIA

Sharing:

11

Description
The URBAN HM70 is powered by a hydraulic motor. It processes material up to 8 cm in diameter and the resulting chips are 6-13 cm long. The source of the hydraulic oil is the aggregate, to which the shredder is connected via the connecting frame and 2 hydraulic quick couplings. We manufacture different types of attachment frames that allow the attachment of the chipper to a wide range of power machines, such as skid steer loaders, agricultural manipulators, construction or municipal machines. The connecting frame is not included with the machine - you will find it in the accessories.

UP TO 80 MM IN DIAMETER
Included with the machine: instruction manual, including declaration of conformity

Weight:505 kg
Max. fresh softwood (pine) diameter:80 mm
Max. fresh hardwood (oak, hornbeam) diameter:65 mm
Max. diameter of dry hardwood (oak, hornbeam):50 mm
Max. prism dimensions (spruce):60 x 60 mm
Max. board dimensions (spruce):190 x 20 mm
Chip length (not adjustable):6 - 13 cm
Opening for the chipping unit:200 x 200 mm
