Jansen BHSM-175 excavator for 3 points (for 20-30 HP tractors) IGJ

4.790 EUR +VAT

Győr-Moson-Sopron county, 9082 Nyúl

Sharing:

10

Description
Jansen BHSM-175 backhoe with 300 mm bucket
The Jansen BHSM-175 backhoe/backhoe attachment is suspended from three points on the tractor and driven directly via the PTO shaft (included). It has its own hydraulic system, so the tractor only needs to be powered via the PTO shaft. The BHSM-175 is supplied from the factory with a 300 mm blade that can be rotated 180 degrees sideways - giving you a large radius of movement!

In addition, the BHSM versions of our excavators can also move the arm laterally, increasing the operating radius even further compared to the standard BHM versions. The BHSM-175 can move sideways by almost 900 mm. This also allows for the machining/machining of strip foundations directly at the house walls!

Your tractor should have at least 25-30 HP. While working, a support can be hydraulically extended to increase stability.

Unlike many competing models, the Jansen BHSM-175 is a very robust and heavy version, weighing 520 kg. The breaking force on the shovel is 1100 kg! The excavator is operated by cross control.

As an option, we offer the following accessories for our backhoe loaders:
- 260 mm bucket
- 500 mm bucket
- 900 mm ditch cleaning bucket without teeth
- 900 mm 900 mm excavator clamping finger - very useful for easy lifting of logs, stones, boards, etc.

Many competitors tempt you with particularly low prices. Not only have we developed these devices ourselves, we also offer competent service (master workshop) and spare parts supply. We usually have all parts in stock.

If you have any questions or problems, we are at your disposal in person or by phone. With us you are talking to competent people, not "call centre agents"!

Technical data:
- Recording: cat I and cat II.
- I, II, II and II. overall length: 2600 mm
- Digging depth: >1750 mm
- Support width: 1380 mm
- Height: max. 3120 mm
- Landing height: max. 1800 mm
- Sweep radius: 180 degrees
- Side shift: 880 mm
- Blade opening angle: 203 degrees
- Shovel capacity: 1100 kg
- Speed: 540
- TLT shaft: accessory
- Hydraulic pressure: 160 bar
- Flow rate: 25 l/min
- Weight: approx. 570 kg
- Weight with packaging: approx. 605 kg
- Packaging dimensions: 1400x1200x1800 mm

Notes:
The excavator is delivered well packed in a steel frame. Please allow approximately 1.5 hours for final assembly. Assembly is normally not a problem, but it is recommended that two people carry out the assembly. You will also need grease for lubrication and about 20-30 litres of hydraulic oil. HLP46 is recommended here. If you have any questions or problems, we will be happy to help you on the phone.

Accessories available:
Tightening finger, ditch cleaning spoon 900 mm, narrow spoon 260 mm
