Self loading caterpillar mini dumper - motorised wheelbarrow - Jansen RD-700S

4.380 EUR

Szlovákia

Sharing:

7

Description
More information about the machine here:

https://www.vivago-gepker.hu/spd/RD-700S/Onrakodo-hernyotalpas-mini-domper-motoros-talicska

More than 700 machines are available on our website!
Service background and spare parts supply in Hungary!

Prices are net prices.

VAT-free purchase.

Companies and sole traders within the European Union and with an EU Community tax number have immediate access to our products and machines at net prices.

www.vivago-gepker.hu

- Personal delivery or home delivery.
- Service background and spare parts supply in Hungary.
- Call, write: +36304346438
- info@vivago-gepker.hu

JANSEN RD-700S
Discover the performance and versatility of the JANSEN RD-700S self-loading crawler mini dumper with hydrostatic drive and hydraulic self-loading bucket! This rugged machine combines powerful performance with excellent off-road capabilities to make your construction projects more efficient.

The hydrostatic drive provides precise and stepless speed control, so you can tackle tough terrain with ease. Thanks to rubber tyres, it provides excellent traction and stability on a variety of surfaces, from muddy construction sites to slopes and hills.

On flat terrain: load capacity up to 800 kg
On slopes of 17% or 10 degrees: up to 450 kg
30% or 17 degrees incline: up to 375 kg

This machine is ideal for transporting sand, soil, gravel, stone and other materials. It can load up to 800 kg! The hydraulic self-loading bucket allows fast and easy loading of materials. Thanks to intuitive operation and powerful lifting power, you can handle heavy loads with ease and save valuable time during each loading process.

FLEXIBLE. ROBUST. POWERFUL.

Our many years of development and manufacturing experience have resulted in a mini-dump truck that stands out from the competition with its robust design and exceptional efficiency, and distinguishes itself with significant improvements.

HYDROSTATIC? NATURALLY! WHY?

- stepless speed control
- linear drive motion with high efficiency
- high torque
- safe and fast overload protection
- very long service life
- low wear compared to conventional drives due to minimal friction
- starting from a standing position at full load is possible
- low maintenance requirements

TECHNICAL SPECIFICATIONS:
Engine: 4-stroke engine, 15 HP, Loncin G420FD
Standard petrol
Starting: electric starter and pull starter
Drive: hydrostatic
Hydraulic power: hydraulic
Hydraulic self-loading bucket
Speed: max 4.4 km/h
Fuel tank capacity: 6.6 litres
Capacity: max. 800 kg, 375 kg on 30% uphill
Dead weight: 575 kg
Bucket dimensions: 1310x660 mm (external dimensions)
Ground clearance: approx. 100 mm front, approx. 100 mm rear
Front edge height of channels: 890 mm from the ground
Assembled dimensions: 2650x740x1130 mm (HxWxM max. top edge, blade down)
Packed dimensions: 1830x770x1300 mm
Weight including packaging: approx. 630 kg

Whether you need to transport construction materials on site or move soil and gravel, the Jansen® RD-700S with hydrostatic drive and hydraulic self-loading bucket is your reliable partner for efficient and successful project execution. Increase productivity and minimize workload with this powerful machine.

FEATURES:

- Powerful 15 HP Loncin G420FD engine with electric starter
- Efficient and economical operation
- Heavy duty and compact dimensions
- Easy handling and intuitive controls
- Unique design with stable driving position
- Reinforced design with reinforced tipping platform (wall thickness 3 mm)
- Tilting platform can be tilted more than 90° (making emptying much easier)
