Vibrating compactor - smooth RCVL 2150

Spišské Podhradie, 053 04 SLOVAKIA

Sharing:

6

Description
The DCSK professional tech compactor model RCVL - a high performance vibratory compactor with smooth drum, particularly suitable for compacting sand and gravel, preparing asphalt or asphalt-free surfaces.


The DCSK profi tech vibratory rollers are equipped with a bidirectional motor with direct power transmission via flexible couplings on the rotating shaft. With 12 vibration damping blocks, adjustable drum cleaning block and self-leveling system with ±15° oscillation (tilt angle). On request, all vibratory compactor models can be equipped with a clutch system offset from the centre to the right side to cover the right wheel tracks when the drum is in operation.


TECHNICAL DATA
Working width (mm) 2150
Overall width (mm) 2420
Clamping force (kgf) 3690
Vibration frequency (strokes/min) 2000-3000
Minimum - maximum oil flow rate ( I/min) 35-70
Minimum - maximum pressure (bar) 150-210
Weight (kg) 1015

More information about the machine here: www.dcsk.hu
